COLOUR
Gloss silver with matt black
CASSETTE
SRAM XS-1275 Eagle, 10-52T, 12 speed
FRAME
6061 alloy, hydroformed T6 aluminium, multi-butted, custom drawn, tapered headtube, internal cable routing, Shape.it Link and 12mm x 148mm Boost dropouts
FORK
Fox Float 38 Performance, 160mm travel, 44mm offset with Grip damper, three-position adjustable, tapered steerer, 110mm x 15mm Boost, E-thru-axle
CRANKSET
Whyte, forged alloy, 155mm, direct mount 36T chainring
REAR SHOCK
Fox Float Performance DPS, EVOL LV, custom tuned for Whyte, three position adjustable compression and rebound damping
BOTTOM BRACKET
N/A
HEADSET
FSA No. 55/35 Orbit 1.5 ZS, 1.8in lower and 1 1/8in upper sealed cartridge bearings
SEATPOST
Crank Brothers HighLine 3, 30.9mm (sizes XS/S/M/L 150mm travel; size XL 170mm travel), Highline ball socket remote lever
REAR HUB
Alloy, e-bike specific, double sealed cartridge bearings, 12mm x 148mm Boost spacing, 32 hole
SADDLE
Fizik Terra Aidon, 145mm wide, Wingflex, S-Alloy Mobius rail
FRONT HUB
Alloy, double sealed cartridge bearings, 15mm x 110mm Boost spacing, 32 hole
HANDLEBAR
Whyte Custom 6061 alloy, 30mm rise, 35mm bar bore, 780mm wide
SPOKES
DT Swiss New Champion 2.0mm, black stainless, brass nipples
STEM
Whyte Enduro, 35mm extension, 35mm bar bore
RIMS
WTB HTZ i30 TCS 2.0 System, asymmetric, sleeved joint, super tough construction, tubeless ready, 32 hole
GRIPS
Whyte Enduro lock-on
TYRE
Maxxis Assigai WT, TR, 2.5in 120TPI, EXO+ casing, 3C Maxx Grip, Dual Compound, Front; Maxxis Minion DHR II WT, TR, 2.4in 120TPI, Double Down, 3C Maxx Terra, Dual Compound, folding bead, rear
BRAKES FRONT
SRAM Code R, four piston hydraulic with sintered metal pads, 220mm diameter disc rotor
SHIFT LEVERS
SRAM AXS Pod, two button MMX, 12 speed
BRAKES REAR
SRAM Code R, four piston hydraulic with sintered metal pads, 200mm diameter disc rotor
FRONT MECH
N/A
BRAKE LEVERS
SRAM Code R, MMX
REAR MECH
SRAM GX T-Type AXS, 12 speed
PEDALS
None
WEIGHT
26.7kg (size M)
