e-BIKE SPECIFIC SPECIFICATION
MOTOR Bosch Performance Line CX 2020 (Gen 4)
75 Nm max Torque
250 W nominal power
2.79 kg 4 Power settings including progressive eMTB mode which automatically adjusts the support
BATTERY Bosch 625 Wh internal PowerTube
Reaches full charge in 8.8 hours with supplied 2A Compact Charger
(or only 3.7 hours with optional aftermarket Fast Charger)
DISPLAY Bosch Purion
SPECIFICATION
COLOUR Matt Gun Metal Black/Rose
CASSETTE SRAM XG-1150 Eagle, 10-42, 11 Speed
FRAME 6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, Custom Drawn, Tapered Headtube, Internal BBX Cable Routing for Dropper Post and 12mm X 148mm Boost Dropout
CHAIN SRAM PC1110, 11 Speed
FORK RockShox Yari RC 27.5", 150mm Travel, 42mm Offset, DebonAir, Motion Control RC Damper, Fast Black Coating, Tapered Steerer, 110mm x 15mm Boost, Maxle Ultimate
CRANKSET SRAM EX1, 165mm, ISIS with X-SYNC 2, Direct Mount 34T for Bosch Gen 4, Black
REAR SHOCK RockShox Deluxe Select + RT, DebonAir, Fast Black Coating, Adjustable Rebound, 2 position compression adjustment
BOTTOM BRACKET N/A
HEADSET FSA No. 57E Orbit ZS, 1 1/2" Lower and 1 1/8" Upper Sealed Cartridge Bearings
SEATPOST Whyte drop.it II Post, 30.9mm, XS/S 125mm Travel, M/L 150mm XL 170mm Travel, Paddle Remote Lever
REAR HUB Alloy, E-bike specific, Double Sealed Cartridge Bearings, 12mm x 148mm Boost Through Axle, 32 Hole
SADDLE Whyte Custom, Triple Panel Design
FRONT HUB Alloy, Double Sealed Cartridge Bearings, 15mm x 110mm Boost Through Axle, 31mm Torque Caps, 32 Hole
HANDLEBAR Whyte Custom 6061 Alloy, 30mm Rise, 35mm Bar Bore, 780mm Wide
SPOKES DT Swiss Champion 2.0mm, Black Stainless, Brass Nipples
STEM Whyte Enduro Stem, 35mm Bar Bore, 35mm Extension
RIMS WTB KOM Trail i30 TCS 2.0 System, Sleeved Joint, Super Tough Construction, Tubeless Ready, 32 Hole
GRIPS Whyte Lock-on V Grip
TYRE WTB Vigilante TCS System 27.5" X 2.5" Tough/High Grip, Tri-Tec triple compound Fast Rolling rubber, Enduro Casing, Front, WTB Verdict TCS System 27.5" X 2.5" Tough/High Grip, Tri-Tec triple compound, Fast Rolling rubber, Enduro Casing, Rear BRAKES FRONT SRAM Guide GE, 4 Pot with Sintered Metal Pads, 200mm Rotor
SHIFT LEVERS SRAM GX-E, Single Click, MMX, 11 Speed
BRAKES REAR SRAM Guide GE, 4 Pot with Sintered Metal Pads, 200mm Rotor
FRONT MECH N/A
BRAKE LEVERS SRAM Code R, MMX
REAR MECH SRAM GX, 11 Speed PEDALS None
WEIGHT 23.9
