The S-Works Crux 5 is the fastest gravel race bike ever made, delivering the lowest real-world Time to Finish through its lightweight, aero design.
The S-Works Crux 5 is the fastest gravel race bike ever made, delivering the lowest real-world Time to Finish through its lightweight, aero design.
Specialized

Specialized S-Works Crux 5 SRAM RED XPLR 49 in Silver/Ahyst Frost/Nebu

£11,999.00
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined

Specialized S-Works Crux 5 SRAM RED XPLR 49 in Silver/Ahyst Frost/Nebu

Season:2027

Brand:Specialized

Code:42948285469834

The S-Works Crux 5 is the fastest gravel race bike ever made.

The S-Works Crux 5 is the lightest and most aero gravel bike, designed to handle dirt like a Tarmac handles pavement. It delivers the lowest real-world Time to Finish of any gravel bike ever made, turning more of your effort into pure speed. This performance is validated across real race courses, real terrain, and real riders. When the goal is the top step, nothing in gravel gets you there faster.

Features:

  • Use: Gravel Racing
  • Frame: FACT 12r Carbon: 789 grams
  • Wheels: Roval Terra Aero CLX
  • Cockpit: Roval Terra Integrated
  • Drivetrain: SRAM RED XPLR
  • Weight: 7.1 kg
Technical Information
  • Use
    Gravel racing
  • Frame
    S-Works Crux 5 FACT 12r Carbon, Rider First Engineered, Threaded BB, 12x142mm thru-axle, flat-mount disc, UDH dropout
  • Fork
    S-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc
  • Brakes
    SRAM RED E1, hydraulic disc
  • Shift Levers
    SRAM RED AXS E1, hydraulic disc
  • Rear Derailleur
    SRAM RED AXS XPLR E1, 13-speed
  • Cassette
    SRAM RED XPLR E1, 13-speed, 10-46t
  • Chain
    SRAM RED E1
  • Crankset
    SRAM RED XPLR E1, Quarq power meter, 40t
  • Bottom Bracket
    Ceramic Speed BB Alpha, BSA DUB
  • Front Tire
    Pathfinder 700x45, Tubeless Ready
  • Rear Tire
    Pathfinder 700x45, Tubeless Ready
  • Front Wheel
    Roval Terra Aero CLX, 27mm internal width, tubeless ready, 50mm depth, 18h, Roval LF18-F hub with ceramic SINC bearings, Centerlock disc, Roval by ARRIS, Composite Aero Spoke with Ti End Pieces
  • Rear Wheel
    Roval Terra Aero CLX, 27mm internal width, tubeless ready, 45mm depth, 24h, Roval LF19-R hub with ceramic SINC bearings, Centerlock disc, Roval by ARRIS, Composite Aero Spoke with Ti End Pieces
  • Inner Tubes
    700x32-50mm, 60mm Presta valve
  • Handlebars
    Roval Terra Cockpit, Integrated Bar/Stem
  • Tape
    Supacaz Super Sticky Kush
  • Saddle
    S-Works Power with Mirror
  • Seatpost
    S-Works Tarmac SL8 Carbon seat post, FACT Carbon, 15mm offset, Lightweight Saddle Clamp
  • Seat Binder
    Integrated Wedge
  • Weight
    7.1 kg
  • Weight Size
    56
  • Size
    49
    52
    54
    56
    58
    61
  • Crank Length
    165mm
    165mm
    170mm
    170mm
    172.5mm
    172.5mm
  • Handlebar Width
    380mm
    380mm
    400mm
    400mm
    420mm
    420mm
  • Stem Length
    75mm
    90mm
    90mm
    100mm
    100mm
    100mm
  • Saddle Width
    155mm
    155mm
    143mm
    143mm
    143mm
    143mm
  • Seatpost Length
    300mm
    300mm
    380mm
    380mm
    380mm
    380mm
  • Stack
    530mm
    547mm
    560mm
    578mm
    598mm
    621mm
  • Reach
    375mm
    382mm
    388mm
    400mm
    412mm
    425mm
  • Head Tube Length
    95mm
    110mm
    125mm
    142mm
    163mm
    188mm
  • Head Tube Angle
    70.5°
    70.75°
    71°
    71.5°
    71.5°
    71.5°
  • BB Height
    278mm
    278mm
    280mm
    280mm
    280mm
    280mm
  • BB Drop
    80mm
    80mm
    78mm
    78mm
    78mm
    78mm
  • Trail
    72mm
    71mm
    69mm
    66mm
    66mm
    66mm
  • Fork Length
    401mm
    401mm
    401mm
    401mm
    401mm
    401mm
  • Fork Rake/Offset
    51mm
    51mm
    51mm
    51mm
    51mm
    51mm
  • Front Center
    594mm
    604mm
    613mm
    626mm
    644mm
    665mm
  • Chainstay Length
    425mm
    425mm
    425mm
    425mm
    425mm
    425mm
  • Wheelbase
    1008mm
    1016mm
    1026mm
    1039mm
    1057mm
    1078mm
  • Top Tube Length
    512mm
    534mm
    543mm
    566mm
    583mm
    603mm
  • Bike Standover Height
    753mm
    766mm
    781mm
    803mm
    823mm
    849mm
  • Seat Tube Length
    445mm
    456mm
    473mm
    497mm
    515mm
    545mm
  • Seat Tube Angle
    75.5°
    74.5°
    74.5°
    74°
    74°
    74°
